Motor Drive Jogging Circuit: Omron 3G3JX-AE004 (Part 2 of 2)

This video, provided by Columbia Gorge Community College, is the first part of a two part lecture that covers programming the jogging function on an Omron 3G3JX-AE004. In this exercise, viewers will learn how to program remote inputs on this motor drive to perform the jogging function. "Various deceleration methods following a jogging event including coasting, deceleration ramp down, and DC injection braking" are also examined. This application exercise may also be replicated on the Omron 3G3MX2 series. This video runs 08:02 minutes in length. The second part of the lecture is available to view separately.
