Example PLC: TECO SG2 PLR (Part 1 of 2)

This video, provided by Columbia Gorge Community College, is the first part of a two part application exercise that examines the TECO SG2 10HRA Programmable Logic Relay (PRL). This PLR is a small and basic programmable logic controller that is commercially available. During this exercise viewers will learn about the layout and specifications of this device. Viewers will also learn how to navigate the menu and program it using dedicated buttons and key strokes. This video runs 12:13 minutes in length. The second part of the lecture is available to view separately.
